Endoscopic recanalization using rendez-vous technique for complete upper esophageal obstruction: a case report
Surgical Technique

Endoscopic recanalization using rendez-vous technique for complete upper esophageal obstruction: a case report

Ahmed Amine Alaoui1, Anne-Sophie Studer1, Georges Rakovich2, Nader Kaouam3, Tareck Ayad4, Henri Atlas1, Pierre Y. Garneau1, Ronald Denis1, Radu Pescarus1

1Minimally Invasive Surgery Department, Hôpital du Sacré Cœur, Université de Montréal, CIUSSS du Nord de l’île de Montréal, Montréal, QC, Canada; 2Thoracic Surgery Department, Hôpital Maisonneuve-Rosemont, Université de Montréal, Montréal, QC, Canada; 3Radio-Oncology Department, Hôpital Maisonneuve-Rosemont, Université de Montréal, Montréal, QC, Canada; 4ENT Department, Hôpital Maisonneuve-Rosemont, Université de Montréal, Montréal, QC, Canada

Correspondence to: Ahmed Amine Alaoui. Minimally Invasive Surgery Department, Hôpital du Sacré Cœur, Université de Montréal, CIUSSS du Nord de l’île de Montréal, 5400, Gouin West, Montréal, QC H4J 1C5, Canada. Email: ahmed.amine.alaoui@umontreal.ca.

Abstract: Esophageal obstruction is a rare late adverse effect after head and neck cancer radiotherapy and chemotherapy treatment. The approach to complete esophageal obstruction is not well established in cases where malignant recurrence has been ruled out. We hereby present the case of a patient that presented with total dysphagia and multiple aspiration episodes. A minimally invasive endoscopic management was proposed for this complete esophageal obstruction. The endoscopic rendez-vous technique for esophageal recanalization requires an antegrade access through the mouth and a retrograde access through a feeding gastrostomy. Two interventional endoscopists locate and measure the length of the stenosis under fluoroscopic control. Once the axis of the two endoscopes is aligned, recanalization is achieved using a needle knife incision followed by balloon dilatation over a guide wire. Nasogastric (NG) tube insertion is performed at the end of the procedure to prevent premature recurrence of the stenosis. Subsequent dilatations were necessary after this procedure to obtain a satisfactory functional result. Post-operative speech therapy follow-up was also required. The endoscopic rendez-vous technique is hence a reliable and safe therapeutic option for short stenosis with transillumination. A multidisciplinary approach and long-term follow-up are mandatory in order to maximize the functional benefit for these complex patients.

Keywords: Esophageal obstruction; endoscopic recanalization; rendez-vous technique; case report


Received: 25 November 2020; Accepted: 05 March 2021; Published: 30 March 2021.

doi: 10.21037/dmr-20-154


Video 1 Endoscopic rendez-vous technique video description.

Introduction

Complete esophageal obstruction is a rare adverse effect after head and neck radiotherapy, with an incidence of 0.8% for the patients with a radiation exposure over 60 Gy (1-4). Other etiologies include the ingestion of caustic substances with subsequent inflammation, fibrosis and collagen deposition in the esophagus (5). With severe clinical symptoms of aphagia and multiple aspirations, complete obstruction significantly affects one’s quality of life. Indeed, patients can no longer swallow their saliva and a feeding gastrostomy becomes necessary for nutritional support (6).

The management of these lesions is technically challenging and the approach to complete esophageal obstruction is not well established in cases where malignant recurrence has been ruled out. Historically, surgery was the only treatment option, with significant mortality and morbidity. More recently, endoscopic techniques are now proposed to restore luminal patency. We hereby describe an endoscopic rendez-vous technique for complete upper esophageal obstruction in accordance with the CARE reporting checklist (available at http://dx.doi.org/10.21037/dmr-20-154).


Case presentation

A 69-year-old patient, with past medical history of inflammatory bowel disease, developed a complete upper esophageal stenosis, 6 months after radiochemotherapy treatment for a left hypopharyngeal epidermoid cancer with proximal esophageal extension. The patient presented with total dysphagia, significant weight loss and multiple aspiration episodes. A complete upper esophageal obstruction, just distal to the upper esophageal sphincter, was confirmed by upper endoscopy and a barium study. A neoplastic recurrence was ruled out. The benefits and the risks of the endoscopic and the surgical management were weighted and the endoscopic rendez-vous technique was chosen (Video 1).

The rendez-vous endoscopic technique requires a complex set-up as well as a team-work approach (Figure 1). As pictured, there should be enough space for the anesthesiologist, the respiratory therapist and the radiology technologist with the fluoroscopy C-arm. Two interventional endoscopists with their assistants and their columns are positioned for an antegrade approach through the mouth and a retrograde approach through the gastrostomy. Importantly, similarly to other third-space endoscopy procedures, the use of CO2 is mandatory. The intervention is performed supine under general anesthesia. Prophylactic antibiotics are given at the beginning of the procedure.

Figure 1 Operating room organization.

The first step is to locate the obstruction by the antegrade approach with an adult gastroscope (Figure 2A) and by the retrograde approach with a pediatric gastroscope (Figure 2B). Once the two scopes are fluoroscopically aligned, a transillumination is performed. Subsequently, using fluoroscopy, the length of the stenosis is measured (Figure 3).

Figure 2 Localization of the stenosis: (A) antegrade approach, (B) retrograde approach. In this case, the stenosis was located just under the upper esophageal sphincter.
Figure 3 Alignment of the two gastroscopes under fluoroscopic view.

The second step is the puncture and dissection of the fibrotic mucous membrane by antegrade approach with the needle knife, after perfect alignment of the two gastroscopes, under endoscopic and fluoroscopic control. Passage of a guidewire from the oral side is used for lumen restoration (Figure 4). Alignment of the two gastroscopes is essential to avoid muscular wall injury. The guidewire is then externalized on one side through the gastrostomy opening and on the other side through the mouth (Figure 5). In cases where the stenosis is right at the upper esophageal sphincter, alignment of the two gastroscopes can be unstable while advancing the guidewire. Use of a transparent straight endoscopic cap may be useful as it improves visualization and tissue traction (Figure 4).

Figure 4 Puncture using a guidewire and a transparent endoscopic cap through antegrade access.
Figure 5 Externalization of the guidewire through the mouth and the gastrostomy.

The third step is the balloon dilatation (Figure 6). The fluoroscopic view is particularly useful to ensure adequate placement of the balloon across the stenosis. The absence of perforation on the recanalization path must be carefully checked following the dilatation with passage of the smaller gastroscope. Alternatively, lack of contrast extravasation effectively rules out significant muscular injury.

Figure 6 Proximal esophageal balloon dilatation (antegrade approach).

Following the successive dilatations, a nasogastric (NG) tube is inserted to prevent early recurrence of the stenosis. Further balloon dilatations might be necessary to successfully insert the NG tube. Another alternative technique in case of unsuccessful attempts is to advance the pediatric gastroscope by the retrograde approach through the stenosis and to externalize it through the mouth (Figure 7). The NG tube is then taped to the end of the pediatric gastroscope. The scope can then be pulled back through the gastrostomy site and the NG tube successfully pushed back in the stomach.

Figure 7 Fixation of the gastroscope to the end of the NG tube. NG, nasogastric.

Further serial dilatations after the discharge are usually necessary to obtain a satisfying functional result. Depending on the clinical evolution, these dilatations can be progressively spaced-out. Close speech therapy follow-up is also required after the procedure.

Follow-up with both barium studies and upper endoscopy is optimal. In our case, a dilatation was planned on post-operative day 2 and the patient was discharged the following day. Subsequent dilatations were necessary to obtain a satisfying functional result. These dilatations were initially performed under general anesthesia to ensure easier cannulation of the stenotic lumen. Initially, they were performed every 1–2 weeks, and they were progressively spaced-out. A laser debridement with the ENT team was also performed. A barium study performed 6 months post recanalization shows a quick passage of contrast through the previous stenotic area (Figure 8). At 10-month follow-up, the patient had a dilatation once every 2 months. He was still undergoing speech therapy and is now tolerating a semi-solid diet. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Informed consent was obtained from the patient.

Figure 8 Barium study 6 months post intervention.

Comments

We hereby present the management of complete esophageal obstruction by an endoscopic rendez-vous technique, which is a good minimally invasive approach for these difficult clinical problems.

Historically, surgery was the only treatment option, with significant mortality and morbidity (7). The surgical options include colonic interposition or jejunal graft for esophageal replacement after the surgical resection of the stenotic portion of the esophagus (3). However, these options are more invasive and not privileged with upper esophageal obstructions. Furthermore, previous use of radiotherapy makes surgical interventions even more challenging.

Hence, multiple minimally invasive therapeutic managements are now proposed to restore luminal patency. Endoscopic alternatives include balloon or bougie dilatation as well as stenting if the stenosis is incomplete. The main risk associated with these techniques is esophageal perforation (6). In the case of total esophageal obstruction with no visible hiatus, another alternative is the retrograde puncture of the stenotic lesion with laryngoscopic guidance and utilization of tactile impression for recanalization (8). However, this technique may not be appropriate for fibrous obstructions.

Recanalization using the rendez-vous technique after transillumination has recently become the most popular endoscopic approach for complete obstructions. Studies suggest that this technique is safe and reliable (9). Fusco et al. reported a series of 19 patients who underwent recanalization by endoscopic rendez-vous technique with a success rate of 94.7%. However, previous studies suggest that strictures length superior to 3 cm and absence of transillumination are factors associated with adverse outcomes with the rendez-vous technique (1). In the absence of transillumination, an alternative is to perform a submucosal tunneling to allow for a passage across the stenosis then followed by dilatation. This technique may be associated with minor cutaneous emphysema and capnomediastinum (10). For example, the Peroral Endoscopic Tunneling for Restoration of the Esophagus (POETRE) technique uses this submucosal tunneling approach (11).

The main adverse outcome of the endoscopic rendez-vous technique is a perforation towards the upper airways. The presence of a pneumomediastinum is not a reliable sign of perforation as the procedure may require prolonged CO2 insufflation and the esophagus does not have a serous membrane. The management of true perforations include stenting, through-the-scope or over-the-scope clips, endoscopic suturing, endoscopic vacuum therapy or in cases of endoscopic failure direct surgical approach. In a large serie, no cases of perforation or mediastinitis were reported for the 19 patients who underwent the procedure (9). In another case-serie, two patients out of eight had evidence of esophageal microperforation after their procedure. Only one of these two patients had clinical subcutaneous emphysema and no subsequent treatments were necessary (6). Other studies report three cases of perforation in 35 procedures, with one of them necessitating an esophageal stent and the two others treated conservatively. One case of self-limited hematemesis in 35 procedures was also reported (1).

One of the goals of this management would be to remove the feeding gastrostomy after the procedure. In Fusco series, only 3 patients out of 19 had their gastrostomy removed (9). In other studies, only 8 of 44 patientshad their gastrostomy eventually removed after the procedure (1). However, it was not possible to determine if these gastrostomies were kept because of persistent dysphagia or prophylactically. Furthermore, in most cases, the rendez-vous technique requires a long-term follow-up with regular dilatations. In Fusco’s series, patients required a mean 11 follow-up dilatations or bouginages during a 2.2-year mean follow-up (9). Auto-bouginages, when possible, can improve the patients’ quality of life. Importantly, a team approach bringing together the interventional endoscopist, head and neck and thoracic surgeon, radiation oncologist, speech therapist and dietician is essential for the long-term success of these procedures. This multidisciplinary team is required to manage the complex medical needs of these patients.

Technical success of recanalization is defined as the restoration of esophageal continuity and the ability to pass the scope through the stenosis. Clinical success is defined as an improvement in the dysphagia score (3). However, there is a discrepancy between technical and clinical success since dysphagia is not only related to the mechanical obstruction, but also to the damage to the nerves and the muscles involved with the radiotherapy (9). Although the rendez-vous approach does not provide total recovery of the esophageal function in most patients, it offers good functional results, and it may significantly improve the patient’s quality of life.

Some strengths and limitations of this study should be mentioned. The patient was closely followed with clinical assessment, endoscopic examination and radiologic studies after the surgery. However, the relatively short follow-up time in this case does not provide information about the long-term results of these endoscopic recanalization procedures.


Summary

Complete upper esophageal obstruction is a clinical challenge and the approach to these obstructions is not well established. The endoscopic rendez-vous technique is a reliable and safe therapeutic option for short stenosis with transillumination. Although the technical success rate appears to be quite high, clinical success may be variable. A multidisciplinary approach and long-term follow-up is mandatory in order to maximize the functional benefit for these complex patients.


Acknowledgments

Funding: None.


Footnote

Reporting Checklist: The authors have completed the CARE reporting checklist. Available at http://dx.doi.org/10.21037/dmr-20-154

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at http://dx.doi.org/10.21037/dmr-20-154). Dr. GR reports personal fees from Medtronic, outside the submitted work. The other authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/ or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Informed consent was obtained from the patient.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.
